LEGEND PVC DOOR SYSTEMS

1

General Features

The Legend System is designed with 6 chambers across an 80mm frame width. Considering the higher performance criteria within the design of the system, the profiles are created with the most appropriate construction elements. The design process is considered to include the properties for insulation (heat and sound), weather resistance, and water tightness. The profiles in the systems are manufactured to the standard TS5358-EN12608.

HIGH PERFORMANCE FOR HEAT INSULATION

The Legend System In order to offer the best level of heat insulation for your home, the Legend System is designed with many important construction elements. This system utilizes an 80 mm platform, 6 chambers, 3 gaskets (middle gasket) included together to provide lower heat and conductivity coefficient (Uf). Uf value of the Legend System is 1.17 17 W/m2K. This system is designed with a width of 80 mm so that it allows for the application of triple glass 80 mm in thickness with lower Uf values (0.6. -0.7-0. 7 W/m2K). This ensures a superior U window value (*Uw:0. 95 W/mK) due to the heat conductivity of the window profile section and the heating value of the glass.

STATIC POWER

The supporting plates used for the profiles in the Legend System have higher static values. This allows for the choice of the most appropriate profiles and plates for the areas. The wind load is stronger than average, considering the static calculations. This higher resistance offered by the supporting plates ensures a wider size of windows, thus enhancing the field of view.

PRODUCT DIVERSITY

The system has a wider group of products. The main profiles in the system are standard frames, casing frames, meeting rails, static meeting rails, casements and casements with drips, inward and outward opening door wings and casement/ wing adaptors. In addition, there is a rich auxiliary profile group to provide solutions for many other details. 90 edge turns, angular edge turns, frontal profiles, elevations, frame extensions, closures and casing profiles etc.

GLASS APPLICATIONS

It is possible to apply glass thicknesses of 24, 30, 36 and 44 mm in the windows and doors. The Legend System offers solutions for all tastes using the variety of color options of Egepen Deceuninck.

* Uf values vary depending on the sizes of the windows and features of the glass.

2

Technical Features

Number of Cubicles: 6
Number of Gaskets: 3 (Middle Gasket)
Gasket: TPE Gray/ Black/
Lath:Single Nail – PCE Gasket
Glass Thickness: 24,30,36,44 mm
Standard: TS 5358 - EN 12608-B Class
Heat Conductivity Coefficient: Uf 1.17 W/m2K

3

Color Options

Fulfills the expectations of the consumers offering a variety of color options.

Krem Antik Meşe Kiraz Altın Meşe Budaklı Winchester Fındık Winchester Vizon Antrasit Gri Koyu Meşe Venge Gümüş Kül Siyah Titanium Sand

ZENDOW PVC DOOR SYSTEMS

1

General Features

Due to the perfect design and aesthetic, the Zendow System easily fits the style of your home. The System is thoroughly considered to suit your requirements.

SUPERIOR INSULATION

Designed in 5 chambers and, 70 mm frame width, the Zendow System provides excellent performance in respect of the heat insulation. The base heat transmission coefficient (Uf) of the system is 1,3 - 1,4 W/m2K as found out as a result of the tests carried out in the IFT Rosenheim. For the applications with the middle gasket, UF is certified as 1,3 W/m2K.

ACOUSTIC PERFORMANCE

Acoustic insulation is very important for the noisy living spaces of today’s world. The Zendow System incorporates 2-chamber fuses providing better acoustic insulation than those manually inserted. In addition, the existing features of PVC and the multi chamber structure of the Zendow System transform to perfect living spaces even those loud locations with intense traffic requiring a maximum level of acoustic insulation.

STATIC POWER

Due to the product range offered, the Zendow System fits your every requirement. The static meeting rails and front profiles provide the best solutions for high wind areas.

RESPECTING THE ENVIRONMENT

The doors in the Zendow System create a healthier environment due to the higher level of insulation and, distinguish with the features such as longevity, low maintenance and 100% recyclability and reprocess-ability at the end of their economic life.

2

Technical Features

Profile Width: 70 mm
Number of Cubicles: 5
Number of Gaskets: 2 (Middle Gasket)
Gasket: TPE Gray/ Black
Lath: Single Nail – PCE Gasket
Glass Thickness: 4, 20, 24, 30, 36, 44 mm
Standard: TS EN 12608-1 B Class
Heat Conductivity Coefficient: Uf 1.3 W/m2K (middle gasket) Uf 1.4 W/m2K

3

Color Options

Fulfills the expectations of the consumers offering a variety of color options.

Krem Antik Meşe Kiraz Altın Meşe Budaklı Winchester Fındık Winchester Vizon Antrasit Gri Koyu Meşe Venge Gümüş Kül Siyah Titanium Sand

EVEREST MAX PVC DOOR SYSTEMS

1

General Features

Everest Max System is designed in 4 cubicles, 70 mm in width and, 2 gaskets. Use of TPE gaskets allows the system for welding on the edges, thus providing strong level of insulation.

The system has a wider product family with 90 mm and 150 mm of casing profiles, interconnection profiles, angular edge turns, 90° and 135° angular edge turns, drips, aluminum threshold, various closure profiles and windowsill mounting profiles. The heights of the door wing and outward opening door wing profiles are optimized, thus increasing the glass surface, i.e. the field of view. Everest Max System includes the options such as Everest Max frames, casing frames, image frames (L54) etc. in order to provide solutions for different details.

The system has a wider product family with 90 mm and 150 mm of casing profiles, interconnection profiles, angular edge turns, 90° and 135° angular edge turns, drips, aluminum threshold, various closure profiles and windowsill mounting profiles. The heights of the door wing and outward opening door wing profiles are optimized, thus increasing the glass surface, i.e. the field of view. Everest Max System includes the options such as Everest Max frames, casing frames, image frames (L54) etc. in order to provide solutions for different details.

2

Technical Features

Profile Width: 70-60 mm
Number of Cubicles: 4
Number of Gaskets: 2 (Middle Gasket)
Gasket: TPE Gray/ Black
Lath: Single Nail – PCE Gasket
Glass Thickness: 4, 20, 24, 30, 36 mm
Standard: TS EN 12608-1 B Class
Heat Conductivity Coefficient: Uf 1.5 W/m2K

3

Color Options

Fulfills the expectations of the consumers offering a variety of color options.

Krem Antik Meşe Kiraz Altın Meşe Budaklı Winchester Fındık Winchester Vizon Antrasit Gri Koyu Meşe Venge Gümüş Kül Siyah Titanium Sand
